Hexagonal Nuts
SKU: HC-1180178764500176896
A nut is a nut, a component that is screwed together with a bolt or screw to tighten. All production and manufacturing machinery must use a component that is divided into several types based on different materials, such as carbon steel, stainless steel, and non-ferrous metals (such as copper).
Key Features
- ✓Third-Party Inspection Support
- ✓Sufficient Inventory Supply
- ✓International Standard Certification
- ✓Custom Processing Service
Contact Us
- Phone：+86 15052357278
- Email：haven@hongchen-steel.com
- WhatsApp：+86 15052357278
Scan to chat
Product Description
A nut is a nut, a component that is screwed together with a bolt or screw to tighten. All production and manufacturing machinery must use a component that is divided into several types based on different materials, such as carbon steel, stainless steel, and non-ferrous metals (such as copper). There are several materials of nuts and some of the popular ones are: ● Zinc-Plated Steel: It is one of the popular and commonly used nut materials for general purpose applications, usually indoor. Depending on the type of manufacturing, the color of the nut may be bluish or yellowish tint. It is a low carbon steel with a Zinc coating that provides moderate corrosion resistance. They are very cheap to manufacture as well.
Specifications
Product Parameters
| US Nut Size Table | ||||||
| Size | Diameter* | Height | ||||
| Hex Nut | Machine Screw Nut | Hex Nut | Jam Nut | Nylock Nut | Machine Screw Nut | |
| #0 | - | 5/32" | - | - | - | 3/64" |
| #1 | - | 5/32" | - | - | - | 3/64" |
| #2 | - | 3/16" | - | - | 9/64" | 1/16" |
| #3 | - | 3/16" | - | - | 9/64" | 1/16" |
| #4 | - | 1/4" | - | - | 9/64" | 3/32" |
| #6 | - | 5/16" | - | - | 11/64" | 7/64" |
| #8 | - | 11/32" | - | - | 15/64" | 1/8" |
| #10 | - | 3/8" | - | - | 15/64" | 1/8" |
| #12 | - | 7/16" | - | - | 5/16" | 5/32" |
| 1/4" | 7/16" | 7/16" | 7/32" | 5/32" | 5/16" | 3/16" |
| 5/16" | 1/2" | 9/16" | 17/64" | 3/16" | 11/32" | 7/32" |
| 3/8" | 9/16" | 5/8" | 21/64" | 7/32" | 29/64" | 1/4" |
| 7/16" | 11/16" | - | 3/8" | 1/4" | 29/64" | - |
| 1/2" | 3/4" | - | 7/16" | 5/16" | 19/32" | - |
| 9/16" | 7/8" | - | 31/64" | 5/16" | 41/64" | - |
| 5/8" | 15/16" | - | 35/64" | 3/8" | 3/4" | - |
| 3/4" | 1-1/8" | - | 41/64" | 27/64" | 7/8" | - |
| 7/8" | 1-5/16" | - | 3/4" | 31/64" | 63/64" | - |
| 1" | 1-1/2" | - | 55/64" | 35/64" | 1-3/64" | - |
| * This is the diameter across the flats. It is also the size of wrench to use. | ||||||
